Citymaster 1650 Outdoor Footpath & Street Sweeper
- Can be driven by anyone holding a Class B driving licence
- Low consumption and emission values
- Efficient hydraulic attachment drive
- Spacious cabin, increased ergonomics at the workplace
- Full LED lighting system plus LED work light
- New 2- or 3-broom comfort sweeping technology
- Smallest turning circle in its class
- Increased driving and operating comfort
With a wide range of different attachments and superstructures available, this machine meets every seasonal challenge in municipal application – and provides fast and economically efficient working. In addition, the Citymaster 1650 offers a comprehensive range of innovative features providing increased operating comfort, safety and efficiency – e.g. the height-adjustable steering column, a 270° camera system or the new 2- or 3-broom comfort sweeping technology.
This vehicle can work almost anywhere
Compact, manoeuvrable, and equipped with excellent climbing power: The Citymaster 1650 can be used on all paved surfaces in the city – without restrictions and at maximum payload. From light-duty maintenance cleaning to efficient basic cleaning tasks after the winter: Hako’s solution covers the entire performance range of a much larger sweeper – and thanks to its slim design and high manoeuvrability, this machine can also work in confined areas and on footpaths. The sophisticated and fully suspended chassis ensures excellent kerb-climbing abilities and trouble-free driving even on bad roads – without any adverse effects on the driver.
Environmentally friendly – and pleasing to the ear
The Citymaster 1650’s distinguishing benefits are its low consumption- and emission values. Intelligent drive systems provide exactly the right kind of power required for the task on hand, which increases the machine’s economic efficiency. The low-emission engine with a particle filter – in combination with Hako’s state-of-the-art sweeping technology providing efficient dust control and particularly low fine dust and particulate emissions on a 4-star level (United PM2.5/PM10 Test) – allows working in the city centre as well as in quiet residential areas. Even early in the morning or late at night.
Multifunctional: For all-season use
The Citymaster 1650 can work all year round. In months with fewer sweeping tasks or when the sweeper can not be used at all due to bad weather conditions, the machine offers additional application options such as winter service tasks or utilization as a versatile implement carrier for green area and road-side greenery maintenance.
Citymaster 650 at a glance
|Engine (type, emission, standard, exhaust gas treatment)
|Diesel 25,5 kW, 2016/1628/EG Stage V
|Type approval / driving license
|Hydrostat, 4×4, 25 km/h
|Chassis and steering
|Hydraulically steered, articulated 4-wheel chassis: steering angle 53?, attachment quick- change system
|23 x 8.50 – 12 standard tyres // 270/50 -12 comfort tyres // 23 x 10.50 – 12 lawn tyres
|Hydrostatic brake acting on all four wheels, service brake at the rear, Mechanical parking brake Hacting on the rear wheels
|ROPS – tested 1 person safety comfort cabin, Frame doors with sliding windows, Hot- water heating/ air conditioning (option)
|1,430 kg (implement carrier), 1,780 kg (sweeper)
|2,200 kg/ 1,200 kg / 1,500 kg (GVW/VA/HA)
|Dimensions (L x B x H)
|3,126 x 1,090 x 1,969 mm
